Description

Distributed Feedback Laser at 760nm Wavelength Laser Diodes DFB Laser



Tunable 760nm Distributed Feedback Laser Diodes with hermetic 14-pin butterfly housing (RoHS compliant), including monitor diode, thermoelectric cooler and thermistor, with PM fiber and angle-polished Connector APC



Datasheet: Distributed Feedback Laser at 760nm Wavelength Laser Diodes DFB Laser



Tunable 760 nm DFB Laser Spectroscopy
with hermetic 14-Pin Butterfly Housing (RoHS compliant) Metrology
including Monitor Diode, Thermoelectric Cooler and Thermistor
with PM Fiber and angle-polished Connector (APC)

Storage Temperature TS °C -40 85
Operational Temperature at Case TC °C -40 85
Operational Temperature at Laser Chip TLD °C 10 50
Forward Current IF mA 130
Reverse Voltage VR V 2
Output Power Popt mW 12
TEC Current ITEC A 1.8
TEC Voltage VTEC V 3.2

Operational Temperature at Case Tcase °C -20 65
Operational Temperature at Laser Chip TLD °C 15 35
